Service Description: These data were obtained from the U.S. Geological Survey's National Elevation Dataset, 1/3 Arc second resolution obtained in 2013. The Grand Canyon Monitoring and Research Center further processed these to build a multidirectional hillshade for the area covered by the DEM. The toolbox used was modified slightly to run on ArcGIS v10.3.1, and originally obtained from Relief Shading repository on GitHub (https://github.com/fveronesi/Relief_Shading), that was created and posted by Dr. Fabio Veronesi and Prof. Dr. Lorenz Hurni from Institute of Cartography and Geoinformation, ETH Zurich Stefano-Franscini-Platz 5, CH-8093 Zurich.

Map Name: GrandCanyonShadedRelief_2011

Legend

All Layers and Tables

Layers:

• Grand Canyon 10m DEM (0)
• Grand Canyon Hillshade (1)

Description: These data were obtained from the U.S. Geological Survey's National Elevation Dataset, 1/3 Arc second resolution obtained in 2013. The Grand Canyon Monitoring and Research Center further processed these to build a multidirectional hillshade for the area covered by the DEM. The toolbox used was modified slightly to run on ArcGIS v10.3.1, and originally obtained from Relief Shading repository on GitHub (https://github.com/fveronesi/Relief_Shading), that was created and posted by Dr. Fabio Veronesi and Prof. Dr. Lorenz Hurni from Institute of Cartography and Geoinformation, ETH Zurich Stefano-Franscini-Platz 5, CH-8093 Zurich.

Copyright Text: USGS, Dr. Fabio Veronesi, Prof. Dr. Lorenz Hurni

Spatial Reference: 102988  (6404)  VCSWkid(115755)  LatestVCSWkid(115755)


Single Fused Map Cache: true

Tile Info:

• Height: 256
• Width: 256
• DPI: 96
• Levels of Detail: 10
  • Level ID: 0 [ Start Tile, End Tile ]
  • Resolution: 264.5838625010584
  • Scale: 1000000
  • Level ID: 1 [ Start Tile, End Tile ]
  • Resolution: 132.2919312505292
  • Scale: 500000
  • Level ID: 2 [ Start Tile, End Tile ]
  • Resolution: 66.1459656252646
  • Scale: 250000
  • Level ID: 3 [ Start Tile, End Tile ]
  • Resolution: 33.0729828126323
  • Scale: 125000
  • Level ID: 4 [ Start Tile, End Tile ]
  • Resolution: 16.53649140631615
  • Scale: 62500
  • Level ID: 5 [ Start Tile, End Tile ]
  • Resolution: 8.268245703158074
  • Scale: 31250
  • Level ID: 6 [ Start Tile, End Tile ]
  • Resolution: 4.134122851579037
  • Scale: 15625
  • Level ID: 7 [ Start Tile, End Tile ]
  • Resolution: 2.0670614257895186
  • Scale: 7812.5
  • Level ID: 8 [ Start Tile, End Tile ]
  • Resolution: 1.0335307128947593
  • Scale: 3906.25
  • Level ID: 9 [ Start Tile, End Tile ]
  • Resolution: 0.5167653564473796
  • Scale: 1953.125
• Format: MIXED
• Compression Quality: 75.0
• Origin: X: -5409200.0
  Y: 6570500.0

• Spatial Reference: 102988  (6404)  VCSWkid(115755)  LatestVCSWkid(115755)


Storage Info:

• Storage Format: esriMapCacheStorageModeCompactV2
• Packet Size: 128

Initial Extent:

XMin: -17501.437584189873
YMin: 433884.8294314116
XMax: 268249.13391695323
YMax: 744823.7846426554
Spatial Reference: 102988  (6404)  VCSWkid(115755)  LatestVCSWkid(115755)

Full Extent:

XMin: -64816.38776588818
YMin: 456549.3813316291
XMax: 315564.0840984677
YMax: 722159.2327825193
Spatial Reference: 102988  (6404)  VCSWkid(115755)  LatestVCSWkid(115755)

Units: esriMeters

Supported Image Format Types: PNG32,PNG24,PNG,JPG,DIB,TIFF,EMF,PS,PDF,GIF,SVG,SVGZ,BMP

Document Info:

Title: gcmrc-publish-topography-services.aprx
Author:
Comments: These data were obtained from the U.S. Geological Survey's National Elevation Dataset, 1/3 Arc second resolution obtained in 2013. The Grand Canyon Monitoring and Research Center further processed these to build a multidirectional hillshade for the area covered by the DEM. The toolbox used was modified slightly to run on ArcGIS v10.3.1, and originally obtained from Relief Shading repository on GitHub (https://github.com/fveronesi/Relief_Shading), that was created and posted by Dr. Fabio Veronesi and Prof. Dr. Lorenz Hurni from Institute of Cartography and Geoinformation, ETH Zurich Stefano-Franscini-Platz 5, CH-8093 Zurich.
Subject: This base map service is provided by the U.S. Geological Survey's Grand Canyon Monitoring and Research Center and designed to be used for online maps of the Grand Canyon region with particular focus on the areas of Glen, Marble and Grand Canyons.
Category:
Keywords: Arizona,Colorado River,Digital Elevation Model,Hillshade,Grand Canyon,Grand Canyon National Park,Marble Canyon,Topography,USGS
AntialiasingMode: Fast
TextAntialiasingMode: Force

Supports Dynamic Layers: false

Resampling: false

MaxRecordCount: 2000

MaxImageHeight: 4096

MaxImageWidth: 4096

Supported Query Formats: JSON, geoJSON, PBF

Supports Query Data Elements: true

Min Scale: 4614126.106970554

Max Scale: 72095.72042141491

Min LOD: 0

Max LOD: 3

Supports Datum Transformation: true



Child Resources:   Info

Supported Operations:   Export Map   Identify   QueryLegends   QueryDomains   Find   Return Updates
